| KB Series 25Bar 30bar 40bar high pressure air compressor | |||||||||||
| Model | Motor Power | Cylinder | Speed | Air Flow | Price | Working Pressure | Air tank | Weight | Dimension | ||
| HP/KW | Dia*No. | R/min | m3/min | CFM | USD | Bar | psi | L | KG | L*W*H/mm | |
| KB-10 | 15(11) | 100*2, 55*1 | 925 | 0.7 | 24.5 | $1,760 | 30 | 435 | 280 | 500 | 1690×690×1190 |
| KB-10G | 15(11) | 0.7 | 24.5 | $1,600 | NO | 450 | 1400×700×850 | ||||
| KB-15 | 15(20) | 120*2, 65*1 | 837 | 1.2 | 42 | $2,200 | 30 | 435 | 350 | 600 | 1750×740×1360 |
| KB-15G | 15(20) | 1.2 | 42 | $1,860 | NO | 480 | 1430×720×990 | ||||
| KBL-15 | 20(15) | 120*2, 80*1 | 900 | 1.3 | 45.5 | $2,200 | 25 | 362.5 | 350 | 600 | 1750×740×1360 |
| KBH-15 | 20(15) | 120*2, 100*1, 55*1 | 800 | 1.2 | 42 | $2,660 | 40 | 580 | 350 | 650 | 1750×740×1400 |
| KBH-15G | 20(15) | 1.2 | 42 | $2,300 | NO | 560 | 1750×740×1000 | ||||
| KB-35G | 30(22) | 155*2, 120*x,55*1 | 700 | 1.7 | 59.5 | $3,814 | 30 | 435 | NO | 800 | 1630×1230×1100 |
| KBH-35G | 30(22) | 1.6 | 56 | $4,016 | 40 | 580 | NO | 800 | 1630×1230×1100 | ||
| KB-45G | 40(30) | 155*2, 120*x,70*1 | 850 | 2.2 | 77 | $4,216 | 30 | 435 | NO | 890 | 1630×1230×1100 |
| KBH-45G | 40(30) | 800 | 2 | 70 | $4,376 | 40 | 580 | NO | 890 | 1630×1230×1100 | |
| 2XKB-15G | 2X15KW | 2*(120*2, 65*1) | 837 | 2.4 | 84 | $4,683 | 30 | 435 | NO | 960 | 1616*1030*1452 |
| 4xKB-15G | 4X15KW | 4*(120*2, 65*1) | 837 | 4.8 | 168 | $7,476 | 30 | 435 | NO | 1920 | 1870*1770*1487 |
| KB Series 25Bar 30bar 40bar high pressure air compressor | |||||||||||
| Model | Motor Power | Cylinder | Speed | Air Flow | Price | Working Pressure | Air tank | Weight | Dimension | ||
| HP/KW | Dia*No. | R/min | m3/min | CFM | USD | Bar | psi | L | KG | L*W*H/mm | |
| KB-10 | 15(11) | 100*2, 55*1 | 925 | 0.7 | 24.5 | $1,760 | 30 | 435 | 280 | 500 | 1690×690×1190 |
| KB-10G | 15(11) | 0.7 | 24.5 | $1,600 | NO | 450 | 1400×700×850 | ||||
| KB-15 | 15(20) | 120*2, 65*1 | 837 | 1.2 | 42 | $2,200 | 30 | 435 | 350 | 600 | 1750×740×1360 |
| KB-15G | 15(20) | 1.2 | 42 | $1,860 | NO | 480 | 1430×720×990 | ||||
| KBL-15 | 20(15) | 120*2, 80*1 | 900 | 1.3 | 45.5 | $2,200 | 25 | 362.5 | 350 | 600 | 1750×740×1360 |
| KBH-15 | 20(15) | 120*2, 100*1, 55*1 | 800 | 1.2 | 42 | $2,660 | 40 | 580 | 350 | 650 | 1750×740×1400 |
| KBH-15G | 20(15) | 1.2 | 42 | $2,300 | NO | 560 | 1750×740×1000 | ||||
| KB-35G | 30(22) | 155*2, 120*x,55*1 | 700 | 1.7 | 59.5 | $3,814 | 30 | 435 | NO | 800 | 1630×1230×1100 |
| KBH-35G | 30(22) | 1.6 | 56 | $4,016 | 40 | 580 | NO | 800 | 1630×1230×1100 | ||
| KB-45G | 40(30) | 155*2, 120*x,70*1 | 850 | 2.2 | 77 | $4,216 | 30 | 435 | NO | 890 | 1630×1230×1100 |
| KBH-45G | 40(30) | 800 | 2 | 70 | $4,376 | 40 | 580 | NO | 890 | 1630×1230×1100 | |
| 2XKB-15G | 2X15KW | 2*(120*2, 65*1) | 837 | 2.4 | 84 | $4,683 | 30 | 435 | NO | 960 | 1616*1030*1452 |
| 4xKB-15G | 4X15KW | 4*(120*2, 65*1) | 837 | 4.8 | 168 | $7,476 | 30 | 435 | NO | 1920 | 1870*1770*1487 |
