| Quantity: | |
|---|---|
5.5m³/min，192cfm,30kw,40hp
30kw,40hp,1600l,9600w,1220h,belt,650kg,G11/2
8bar
LG30-8GA is a electric screw compressor driven by 30kw/40hp motor, direct driving. It is applicant in workshop and plants to drive pneumatic tools. Its air flow 5.5m3/min @8bar, applicant in workshop and plants to drive pneumatic tools.
LG electric screw compressor sepcifiction. | |||||||||||
Model | Working pressure | Capacity | Motor power | Dimension | Drive | Weight | Output | ||||
bar | m³/min | cfm | kw | hp | L | W | H | KG | inch | ||
LG30-8GA | 8 | 5.5 | 192 | 30 | 40 | 1600 | 9600 | 1220 | direct | 650 | G11/2 |
LG Series Screw Air Compressor is Kaishan's standard series of screw ain compressor. Each model reaches level two energy efficiency. Among compressors that reach level two energy efficiency defined in the national energy efficiency standard Kaishan's LG Series is the most cost effective. This kind screw compressor have below advantages
Air End -Rotor
SKK series rolor profiles onginaled in England but are owned by Kaishan Compressor
SKK series air end is our time proven rolary screw alr end The precision machined ar end increases the reliabty and operating life.
Pressure Controller and Solenoid Valve
Highly reliable compact design.
Easy to install.
Fast response 2-way and 3-way exiended bearing life solenoid valves.
Drive Motors
lEC high efficiency drive motors. IP54 and high temperature F class rating.
Direct coupling design for extended bearing life.
Easy maintenance with grease refill port.
Integrated Microprocessor Controller
Easy to use and maintenance free Constant readout of pressure and temperature.
Selective readout of all operating and maintenance parameters. Safety shutdown.
Provides 24 hours automatic start-stop operation.
Lead-lag and sequencing with multiple compressors.
Superior Filtration System
Ultra efficient Kerry inlet air filters provide clean air that traps dirt particles to less than 3 microns Easy spin on Kerry Oil filters.
Pressure Differential gauges for easy filter maintenance.
LG30-8GA is a electric screw compressor driven by 30kw/40hp motor, direct driving. It is applicant in workshop and plants to drive pneumatic tools. Its air flow 5.5m3/min @8bar, applicant in workshop and plants to drive pneumatic tools.
LG electric screw compressor sepcifiction. | |||||||||||
Model | Working pressure | Capacity | Motor power | Dimension | Drive | Weight | Output | ||||
bar | m³/min | cfm | kw | hp | L | W | H | KG | inch | ||
LG30-8GA | 8 | 5.5 | 192 | 30 | 40 | 1600 | 9600 | 1220 | direct | 650 | G11/2 |
LG Series Screw Air Compressor is Kaishan's standard series of screw ain compressor. Each model reaches level two energy efficiency. Among compressors that reach level two energy efficiency defined in the national energy efficiency standard Kaishan's LG Series is the most cost effective. This kind screw compressor have below advantages
Air End -Rotor
SKK series rolor profiles onginaled in England but are owned by Kaishan Compressor
SKK series air end is our time proven rolary screw alr end The precision machined ar end increases the reliabty and operating life.
Pressure Controller and Solenoid Valve
Highly reliable compact design.
Easy to install.
Fast response 2-way and 3-way exiended bearing life solenoid valves.
Drive Motors
lEC high efficiency drive motors. IP54 and high temperature F class rating.
Direct coupling design for extended bearing life.
Easy maintenance with grease refill port.
Integrated Microprocessor Controller
Easy to use and maintenance free Constant readout of pressure and temperature.
Selective readout of all operating and maintenance parameters. Safety shutdown.
Provides 24 hours automatic start-stop operation.
Lead-lag and sequencing with multiple compressors.
Superior Filtration System
Ultra efficient Kerry inlet air filters provide clean air that traps dirt particles to less than 3 microns Easy spin on Kerry Oil filters.
Pressure Differential gauges for easy filter maintenance.
